Media: | Hydraulic | Material: | Iron |
---|---|---|---|
Copy: | Poclain |
1. Product Features:
1). Radial piston type;
2). Adopt Imported Bearing and Oil Seal, etc.
3). Modular design, High efficiency, High pressure and smooth running even at very low speeds.
4). Permissible Radial and Axial load, Motor with multi-disc brake, Motor emission control.
2. Applications:
Mining Machinery:Coal Mine Drill, Heavy Duty Handling Car.
Engineering Machinery:Scavenging Machine, Aircraft Tractor, Beam Carrier/Hoisting Machine.
Farming Machinery: Mini Farming Vehicle, Ditcher.
3. Specifications:
Type | MS02-8 | MS02-9 | MS02-0 | MS02-1 | MS02-2 | |||||
Full/Semi | Full/Semi | Full/Semi | Full/Semi | Full/Semi | ||||||
Displacement(ml/r) | 172 | 86 |
|
| 213 | 106 | 235 | 118 | 255 | 128 |
Max power(kw) | 16 | 10 |
|
| 16 | 10 | 16 | 10 | 16 | 10 |
Pressure discrepancy 10MPa Torque | 273 | 136 |
|
| 340 | 170 | 351 | 175 | 405 | 202 |
Rated torque(N. m) | 643 |
| 796 | 878 | 953 | |||||
Rated pressure(MPa) | 25 |
| 25 | 25 | 25 | |||||
Max pressure(MPa) | 40 |
| 40 | 40 | 35 | |||||
Rated speed(r/min) | 140 |
| 140 | 140 | 120 | |||||
Speed range(r/min) | 0-310 |
| 0-310 | 0-310 | 0-260 |
